Please roll mouse over schematic to view photos.
Unit 3 Steam Generator A Unit 3 Pressurizer Unit 3 Steam Generator B Unit 3 Core Makeup Tank Unit 3 Accumulator Tank Unit 3 Accumulator Tank Unit 3 Core Makeup Tank Surge Line Hot Leg Cold Leg Cold Leg Reactor Vessel Cold Leg Hot Leg Cold Leg Unit 3 PRHR Heat Exchanger

AP1000® Passive Core Cooling System provides safety injection and reactor coolant makeup from core makeup tanks, accumulators and in-containment refueling water storage tank. It also provides for passive residual heat removal. Graphic courtesy of Westinghouse Electric Company LLC. © 2012 All rights reserved.
